Screw (SSHS-SD Series)
Product Details:
X
Product Description
Application
Reducing the size of equipment and devices
Characteristics
Socket head cap screws with special low profile made of stainless steel.
The head height for all screws is 1.5 mm or less. Intended for reducing the size of devices and applications with limited overhead space.
The following two types of stainless materials are available as standard.
SSHS SUSXM7S.S. grade
SSHL SUS316L
Compared to SUS304, SUS316L has excellent hydrogen embrittlement resistance, fluorine and chlorine gas resistance, and heat resistance. This screw also has corrosion resistance against chemical products and seawater environments that matches or exceeds SUS304.
SUS316L is nonmagnetic.
To distinguish from SSHS, SSHL has a cup point tip.
Specifications:
Diameter:
Min.: 3 mm (0.12 in)
Max.: 10 mm (0.39 in)
Length:
Min.: 6 mm (0.24 in)
Max.: 30 mm (1.18 in)
